Inductive analog sensor ANT2-8 2084/85 V1

Inductive proximity sensor

Inductive analog sensor ANT2-8 2084/85 V1

  • Inductive analog
  • Output 0 V ... 10 V
  • Output 0 mA ... 20 mA
  • Non-flush mountable
  • Product Detail

Datasheet excerpt: Technical data of  ANT2-8 2084/85 V1

General specifications
Output type Analog current output or analog voltage output
Installation non-flush
Output polarity DC
Measurement range 2 ... 8 mm
Output type 3-wire
Nominal ratings
Operating voltage 18 ... 30 V
Output signal 0 ... 20 mA 0 ... 10 V
Reverse polarity protection reverse polarity protected
Linearity error ± 0.5 %
Temperature drift ≤ 0.2 % / K v.E.
Repeat accuracy < 0.02 mm
No-load supply current ≤ 16.25 mA
Load resistor voltage output: ≥ 4,7 kΩ
current output: ≤ 200 Ω
Electrical specifications
Linearity ± 5 % v.E.
Compliance with standards and directives
Standard conformity
Standards EN IEC 60947-5-2
Approvals and certificates
CCC approval CCC approval / marking not required for products rated ≤36 V
Ambient conditions
Ambient temperature -25 ... 70 °C (-13 ... 158 °F)
Mechanical specifications
Connection type M12 x 1
Housing material brass, nickel-plated
Sensing face PBT
Degree of protection IP67
Dimensions
Length 70 mm
Diameter 18 mm
