General specifications
|
|
Switching function
|
Normally open (NO)
|
|
Output type
|
Two-wire
|
|
Rated operating distance
|
25 mm
|
|
Installation
|
non-flush
|
|
Output polarity
|
AC/DC
|
|
Reduction factor rAl
|
0.47
|
|
Reduction factor rCu
|
0.44
|
|
Reduction factor r304
|
0.77
|
|
Output type
|
3-wire
|
|
Nominal ratings
|
|
Switching frequency
|
30 Hz
|
|
Hysteresis
|
3 ... 15 typ. 5 %
|
|
Reverse polarity protection
|
reverse polarity tolerant
|
|
Short-circuit protection
|
yes
|
|
Voltage drop
|
≤ 8 V
|
|
Rated operating current
|
4 ... 500 mA AC/DC
|
|
Off-state current
|
≤ 0.8 mA
|
|
Operating voltage indicator
|
LED, green
|
|
Switching state indicator
|
LED, yellow
|
|
Electrical specifications
|
|
Rated operating voltage
|
20 ... 250 V AC/DC
|
|
Compliance with standards and directives
|
|
Standard conformity
|
|
|
|
Standards
|
EN IEC 60947-5-2
|
|
Approvals and certificates
|
|
UL approval
|
cULus Listed, General Purpose
|
|
CSA approval
|
cCSAus Listed, General Purpose
|
|
CCC approval
|
Certified by China Compulsory Certification (CCC)
|
|
Ambient conditions
|
|
Ambient temperature
|
-25 ... 70 °C (-13 ... 158 °F)
|
|
Storage temperature
|
-40 ... 85 °C (-40 ... 185 °F)
|
|
Mechanical specifications
|
|
Connection type
|
cable PUR , 2 m
|
|
Core cross section
|
0.5 mm2
|
|
Housing material
|
brass, nickel-plated
|
|
Sensing face
|
PBT
|
|
Degree of protection
|
IP67
|
|
Dimensions
|
|
|
|
Length
|
51 mm
|
|
|
Diameter
|
30 mm
|
