intrinsically safe NAMUR proximity switches are mainly used in equipment and environments that require explosion protection, such as coal mines, petrochemicals, etc. The NAMUR signal is the most widely used intrinsically safe digital input and frequency input standard signal in the world. The earliest is the German standard (DIN19234). Later it became a European standard (EN 50227, DIN EN 60947-5-6). The NAMUR signal is a passive 2-wire system, nominal 8VDC power supply, 1mA and 3mA switching signals. NAMUR type sensors are intrinsically safe explosion-proof instruments and are usually used in conjunction with isolated safety barriers.

● Detect various metal objects	--
● With surge, overload, short circuit and reverse polarity protection functions	DC 2 Wire NC
● Shell material: PBT	--
● Protection grade IP66 (IEC)	--
● Ambient temperature: -25℃~+70℃	--

Product Model	KJT-NJ-8
Installation method	Non-Flush
Detection distance	2mm
Working temperature	-25℃~+70℃
Specifications	40*40*118
Operating Voltage	6-12V DC
Ripples	-
No-load current	>2.2mA（OFF）< 1.1mA（ON）
Maximum load current	<10mA
Voltage drop	-
On-off level	150Hz
Hysteresis	<15(Sr)
Overload protection current	-
Short circuit protection	-
Repeat accuracy	<3.0%(Sr)
Temperature drift	<10%(Sr)
Response time	0.5ms
Connection method	Terminal Type
Protection level	IP66
Sensing surface material	PBT
Shell Material	PBT
EMC	RFI>3V/M / EFT>1KV  /  ESD>4KV(contact)
Shock/Vibration	IEC 60947-5-2,Part7.4.1  /  IEC 60947-5-2,Part7.4.2
