Inductive sensor NBB10-30GM50-WS

Inductive proximity sensor

Inductive sensor NBB10-30GM50-WS

  • Basic series
  • 10 mm flush
  • 2-wire AC
  • Product Detail

Datasheet excerpt: Technical data of  NBB10-30GM50-WS

General specifications
Switching function Normally open (NO)
Output type Two-wire
Rated operating distance 10 mm
Installation flush
Output polarity AC
Assured operating distance 0 ... 8.1 mm
Actual operating distance 9 ... 11 mm
Reduction factor rAl 0.33
Reduction factor rCu 0.28
Reduction factor r304 0.81
Output type 2-wire
Nominal ratings
Operating voltage 20 ... 253 V
Switching frequency 0 ... 20 Hz
Hysteresis typ. 5 %
Reverse polarity protection reverse polarity tolerant
Voltage drop < 5 V (IL > 50 mA); < 8 V (IL < 50 mA)
Momentary current
(20 ms, 0.1 Hz)
0 ... 1600 mA
Operating current 5 ... 200 mA
Off-state current 0 ... 1.7 mA
Operating voltage indicator LED, green
Switching state indicator LED, yellow
Compliance with standards and directives
Standard conformity
Standards EN IEC 60947-5-2
Approvals and certificates
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
CCC approval Certified by China Compulsory Certification (CCC)
Ambient conditions
Ambient temperature -25 ... 70 °C (-13 ... 158 °F)
Mechanical specifications
Connection type cable PVC , 2 m
Core cross section 0.75 mm2
Housing material brass, nickel-plated
Sensing face PBT
Degree of protection IP67
Cable
Cable diameter 6.4 mm ± 0.2 mm
Bending radius > 10 x cable diameter
Dimensions
Length 50 mm
Diameter 30 mm
Note 1) In the temperature range below 0 °C, permissible operating voltage Ub 80...253 V
Safety fuse ≤ 0.3 A (quick-blow) according to IEC 60127-2 Sheet 1
Recommendation: after a short circuit, check that the device is functioning correctly.
