General specifications
|
|
Switching function
|
complementary
|
|
Output type
|
PNP
|
|
Rated operating distance
|
30 mm
|
|
Installation
|
non-flush
|
|
Output polarity
|
DC
|
|
Assured operating distance
|
0 ... 24.3 mm
|
|
Reduction factor rAl
|
0.33
|
|
Reduction factor rCu
|
0.31
|
|
Reduction factor r304
|
0.74
|
|
Reduction factor rBrass
|
0.38
|
|
Output type
|
4-wire
|
|
Nominal ratings
|
|
Operating voltage
|
10 ... 30 V
|
|
Switching frequency
|
0 ... 230 Hz
|
|
Hysteresis
|
typ. 5 %
|
|
Reverse polarity protection
|
reverse polarity protected
|
|
Short-circuit protection
|
pulsing
|
|
Voltage drop
|
≤ 2 V
|
|
Operating current
|
0 ... 200 mA
|
|
Off-state current
|
0 ... 0.5 mA
|
|
No-load supply current
|
≤ 20 mA
|
|
Time delay before availability
|
80 ms
|
|
Operating voltage indicator
|
LED, green
|
|
Switching state indicator
|
LED, yellow
|
|
Functional safety related parameters
|
|
MTTFd
|
1230 a
|
|
Mission Time (TM)
|
20 a
|
|
Diagnostic Coverage (DC)
|
0 %
|
|
Compliance with standards and directives
|
|
Standard conformity
|
|
|
|
Standards
|
EN IEC 60947-5-2
|
|
Approvals and certificates
|
|
UL approval
|
cULus Listed, General Purpose
|
|
CCC approval
|
CCC approval / marking not required for products rated ≤36 V
|
|
Ambient conditions
|
|
Ambient temperature
|
-25 ... 85 °C (-13 ... 185 °F)
|
|
Mechanical specifications
|
|
Connection type
|
screw terminals
|
|
Core cross section
|
max. 2.5 mm2
|
|
Housing material
|
PA/metal with epoxy powder coating
|
|
Sensing face
|
PA
|
|
Housing base
|
metal
|
|
Degree of protection
|
IP68 / IP69K
|
|
Mass
|
225 g
|
|
Dimensions
|
|
|
|
Height
|
40 mm
|
|
|
Width
|
40 mm
|
|
|
Length
|
118 mm
|
|
Note
|
Tightening torque: 1.8 Nm (housing)
|
