Compared with traditional photoelectric switches that rely on light quantity feedback to detect objects, the KJT-FG30 photoelectric sensor using TOF technology has the following advantages: 1: More accurate positioning 2: Reduce the interference caused by the color, curvature, environment, etc. of the object surface 3: The highest possible Switching frequency up to 1000 Hz4: Stable detection of transparent objects. 5: Not affected by sunlight, can be used outdoors. 6: Achieve longer detection distance (diffuse reflection can reach up to 4 m! It is the only laser photoelectric sensor on the market)

Project model	Type	2-point teaching type
	NPN	KJT-FG30N
	PNP	KJT-FG30P
	RS485	KJT-FG30
Detection distance range		50～2000, 50～4000 setting distance (white paper, black paper 200×200mm)
Spot diameter (reference value)		4*2cm（1m）;12*6cm(2.5m)；14*7cm(4m)
Reflectivity characteristics (white and black error)		Less than 5% of the set distance (set distance 2000mm)
Light source (luminescence wavelength)		Infrared laser (940nm) Class1 (IEC/EN60825-1：2014)
Voltage		DC10～36V (including Ripple (p-p) 10%) Class2
Current consumption		20mA or less
Output load		Load power supply voltage DC26.4V or less Class2, load current 100mA or less (Residual voltage: load current within 10mA: 1V or less, load current within 10 to 100mA: 2V or less) Open connector output type (NPN/PNP output varies by model)
Protection circuit		Power supply reverse connection protection, output short circuit protection, output reverse connection protection
Frequency		500hz
Distance setting		Teaching method
Use ambient illumination	Illumination of light receiving surface	Sunlight: below 10,000lx
Ambient temperature range		During operation: -20～﹢55℃, during storage: -40～﹢70℃ (no icing, no condensation)
Ambient humidity range		During operation: 35~85%RH, during storage: 35~95%RH (no condensation)
Insulation resistance		20MΩ or more (DC500V megger)
Withstand voltage		AC1000V 50/60Hz 1min
Vibration (durability)		10～55Hz, complex amplitude 1.5mm, 2h in each direction of X, Y and Z
Impact (durability)		500m/s2 3 times in each direction of X, Y, Z
Protective structure		P65 (IEC60529)
Indicator light		Action indicator (red), stability/communication indicator (green)
Connection method		Wire lead type (standard wire length 2m), M8 connector relay type (standard wire length 0.3m), M12smart click connector relay type (standard wire length 0.3m)
Quality (Packaging state/body only)	Lead-out type	Resin case type: about 120g/about 65g
Material	Shell	ABS
	Lens Department	PMMA
	Display part	PET
	Accessories	Instruction manual (Chinese/English), compliance sheet, note. Installation accessories are sold separately.
