M18 Laser Photoelectric Sensor (Diffuse Reflective) equivalent to E3RB-DP25-F2

Cylindrical Photoelectric sensor

M18 Laser Photoelectric Sensor (Diffuse Reflective) equivalent to E3RB-DP25-F2

Photoelectric sensor, M18 threaded barrel, radial type, metal, infrared LED, diffuse, 300 mm, PNP, Light-ON/Dark-ON, inverted logic, M12 connector
  • Product Detail

Specifications

Shape Cylindrical radial
Sensing method Diffuse reflective
Sensing distance 300 mm
Setting method Manual adjustment
Connection method Connector M12
Output type PNP
Operation mode Dark-ON, Light-ON
Response time 0.5 ms
Material housing Brass, nickel plated
Thread size M18
Product Length (unpacked) 61 mm
Type of light Infrared light
Power supply voltage 10-30 V
Degree of protection (IP) IP67/IP69K
