Photoelectric switches are controlled by converting changes in light intensity into electrical signals.KJT photoelectric switches are available in a wide range of products, such as diffuse reflective, specular reflective, counter-reflective, cylindrical, square, slotted, relay outputs, etc. KJT standard photoelectric switches are available in a wide range of products, such as diffuse reflective, specular reflective, relay outputs, etc. KJT standard photoelectric switches are available in a wide range of products, including diffuse reflective, specular reflective, relay outputs, etc.

Product type	KJT-FJ18
Reflective mode	Diffuse reflective
Detection distance	0.1
Distance tolerance	<10%(Sr)
Shell material	Copper nickel plated or plastic
Operating voltage	10-30VDC
Ripple	≤10%
Switching hysteresis	＜15%
Light source	Infrared light (880nm)
Suitable for large output currents	200mA
No load current	≤30mA
Voltage drop	≤2.5V
Sensitivity adjustment	Trimmer 1tum
Response time	＜5ms
Short circuit protection	Yes
Power-up protection	Yes
Operating temperature	-25°C- 55°C
Environmental humidity	35 to 85% RH
Suitable for intensity light	≤10.000Lux
Protection level	IP66
