Datasheet excerpt: Technical data of NBB8-30GM60-I3
General specifications | ||
---|---|---|
Output type | Analog current output | |
Installation | flush | |
Output polarity | DC | |
Measurement range | 3 ... 8 mm | |
Output type | 3-wire | |
Nominal ratings | ||
Operating voltage | 15 ... 30 V DC | |
Repeat accuracy | 0 ... 200 µm | |
Recovery time | 1 ... 10 ms typ. 5 ms | |
No-load supply current | ≤ 12 mA | |
Analog output | ||
Output type | 0 ... 20 mA | |
Slope of output characteristic | 4 mA / mm | |
Linearity error | ≤ ± 5 % of full-scale value | |
Load resistor | ≤ 500 Ω | |
Rate of current rise | ||
0 ... 20 mA | ≤ 50 A/s | |
20 ... 0 mA | ≤ 20 A/s | |
Temperature drift | ≤ ± 0.15 %/K of the measured value | |
Residual ripple | ± 125 µA | |
Compliance with standards and directives | ||
Standard conformity | ||
Standards | EN IEC 60947-5-2 | |
Approvals and certificates | ||
UL approval | cULus Listed, General Purpose | |
CCC approval | CCC approval / marking not required for products rated ≤36 V | |
Ambient conditions | ||
Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) | |
Mechanical specifications | ||
Connection type | cable PVC , 2 m | |
Core cross section | 0.75 mm2 | |
Housing material | brass, nickel-plated | |
Sensing face | PBT | |
Degree of protection | IP67 | |
Cable | ||
Cable diameter | 6.4 mm ± 0.2 mm | |
Bending radius | > 10 x cable diameter | |
Dimensions | ||
Length | 60 mm | |
Diameter | 30 mm |
