KJT-XTU-822 Digital Thermometer

Products

KJT-XTU-822 Digital Thermometer

  • brand name:Digital display bimetal thermometer
  • model number:KJT-XTU-822/804
  • Temperature range:The default temperature range is -50-200℃, please contact customer service for quotation if you need other temperature range.
  • Product Size:Dial diameter: 100mm
  • Installation:Default thread is movable thread M27*2 (thread O.D. 27mm. Pitch 2mm), G1/2, M20X1.5.
  • power supply:Default is 2 x 5 batteries
  • Display Color:Black digital display
  • dial panel:Switched as standard
  • material (that sth is made of):All 304 stainless steel
  • Insertion length:Customized
  • protection class:IP66
  • Explosion-proof symbol:ExdII CT6 Gb
  • Product Detail

1

Digital thermometer shape using all stainless steel 304 material, strong and beautiful and durable, the use of imported chip assembly, high stability, built-in 1 section of 5 batteries, micro-power consumption, low temperature drift, integrated circuits and liquid crystal display, without external power supply, the applicability of a new type of field temperature display instrument, is the traditional field pointer bimetallic, thermometer, now want to replace the product, widely used in electric power iron and steel all kinds of machinery and equipment supporting.

universal suffrage clarification
KJT-XTU-822
digital thermometer
output method 822 radial direction
802
axis
clamshell A Plastic Engineering Housings
B Stainless steel 304 housing
Accuracy Class 1 1%
2 0.5%
process connection A 20*1.5
B G1/2
C 27*2
D Other orders are specified
Power supply method N Built-in 5-cell battery
Temperature range -50+200 ℃ Customer Choice


4


11
